Eurocom D900F Panther Workstation - Manual (Page 100)

Upgrading The Computer
6 - 6 Upgrading the Hard Disk Drive(s)
6
Removing the Hard Disk(s) in the Secondary HDD Bay
1. Turn off the computer, and turn it over and remove the battery.
2. The secondary hard disk bay is located under the battery compartment.
3. Remove screw .
4. Slide the hard disk assembly in the direction of the arrow .
5. Lift the hard disk assembly out of the compartment.
6. Remove the screws - to release the hard disk from the case.
RAID Hard Disks
All hard disks in a RAID
should be identical (the
same size and brand) in
order to prevent unex-
pected system behavior.
Figure 6 - 4
Secondary HDD
Removal
21
22
23
24 27
22
21
23
24
25
27
26
