Upgrading The Computer
6 - 20 Upgrading the Video Card
6
6. Secure the card with screws & ( Figure 6 - 17 on page 6 - 17 ).
7. Place the heatsink back on the card, and secure the screws in the order indicated
in
Figure 6 - 16 on page 6 - 16 .
8. Attach the video card fan and secure with the screws as indicated in Figure 6 - 15
on page 6 - 16 .
9. Reinsert the component bay cover, and secure with the screws as indicated in
Figure 6 - 14 on page 6 - 15 .
21 22
