36

Chapter 5 Parameter Definitions

SPEED

The speed of an Ethernet port.

The values 10, 100, 100 select 10 MHz, 100

MHz and 1 GHz respectively. An “H”

appended to the value indicates half-duplex

operation; values without the appended “H”

are full-duplex operation.

One of:

• AUTO
• 10
• 100
• 1000
• 10H
• 100H
• 1000H

Default = AUTO

SRTX

Number of times a packet of SIGTRAN

information can be retransmitted before

determining that the SIGTRAN link has gone

out of service

2 to 10

SS7MD

SS7 signaling mode:

• ITU14 – ITU operation with 14 bit Point

Code

• ITU16 – ITU operation with 16 bit Point

Code

• ITU24 – ITU operation with 24 bit Point

Code

• ANSI – ANSI operation with 24 bit Point

Code

One of:

• ITU14
• ITU16
• ITU24
• ANSI

STS

A timeslot within a PCM interface on a board

used for monitoring information sent by the

monitored object. The format is:
xx-y-zz
where:

• xx = board position (

BPOS

)

• y = PCM within a board
• zz = timeslot

xx – 1 to 3
y – 1 to 4
zz – 1 to 31

SUBNET

Subnet mask for the network to which the

Signaling Gateway is connected specified

using dot notation, that is, www.xxx.yyy.zzz

www – 0 to 255
xxx – 0 to 255
yyy – 0 to 255
zzz – 0 to 255

Default =

255.255.255.0

SUBNET2

2

nd

Subnet mask for the network to which

the Signaling Gateway is connected

specified using dot notation, that is,

www.xxx.yyy.zzz

www – 0 to 255
xxx – 0 to 255
yyy – 0 to 255
zzz – 0 to 255

Default =

255.255.255.0

SUBNET3

3

rd

Subnet mask for the network to which

the Signaling Gateway is connected

specified using dot notation, that is,

www.xxx.yyy.zzz

www – 0 to 255
xxx – 0 to 255
yyy – 0 to 255
zzz – 0 to 255

Default =

255.255.255.0

SUBNET4

4th Subnet mask for the network to which

the Signaling Gateway is connected

specified using dot notation, that is,

www.xxx.yyy.zzz

www – 0 to 255
xxx – 0 to 255
yyy – 0 to 255
zzz – 0 to 255

Default =

255.255.255.0

SYNCPRI

The priority the PCM is given to provide

clock synchronization:

• 0 – Indicates never provide clock

synchronization

• 1 – Highest priority that PCM should

provide clock synchronization

• 32 – Lowest priority, that is, other PCMs

have precedence

0 to 32

Default = 0

SYSID

System identity

0 to 12

SYSREF

The system reference number

0 to 999

Default = 0

SYSTYPE

The type of system to be run

One of:

• SGW
• DSC
• SIU

Table 2. Parameter Definitions (Continued)

Name

Description

Range

Notes
