Dialogic ® SS7G2x Signaling Server SGW Mode User Manual Issue 4
9.4.5 SIGTRAN Link Measurements File Format
2001-12-31,13:07:25,600,2,886,888,5,0,0
2001-01-01,01:01:00,86400,5,5000,6000,1000,1000,65
2001-11-22,19:07:38,3600,1,0,0,0,0,0
9.4.6 System Measurements File Format
2005-11-16,14:40:01,0,231,155,8462
2005-11-16,14:45:01,0,368,159,8762
2005-11-16,14:50:01,0,380,164,9062
9.5 RDC Configuration and Usage
This section provides a guide to the configuration of the Signaling Gateway for RDC operation, the text
demonstrates by example, the man machine language (MML) commands and parameters required to invoke
those services that transfer data to and from the RDC.
9.5.1 RDC Initialization
Initialize the RDC using the CNRDI command:
CNRDI : RDC =1, IPADDR =123.123.123.12, USER =ANONYMOUS, PASSWORD =ANONYMOUS, LABEL =MYWORKSTN;
Unblock the RDC using the MNBLE command:
MNBLE : RDC =1;
Check the status of the RDC with the STRDP command:
Field Title Example Range Description
1 Date 2001-12-31 yyyy-mm-dd
Date when measurements
collected
2 Time 13:07:25 hh:mm:ss
Time when measurements
collected
3 Period 600 0 to 4294967295
Duration of measurement
period in seconds
4 SIGTRAN Link 2 0 to 32 SIGTRAN Link Number.
5 Chunks Received 886 0 to 4294967295
Number of chunks received
in the link.
6 Chunks Transmitted 888 0 to 4294967295
Number of chunks
transmitted in the link.
7
Chunks
Retransmitted
5 0 to 4294967295
Number of chunks
retransmitted in the link.
8
Number of times out
of service.
0 0 to 4294967295
Duration in abort and
shutdown states.
9
Out of service
duration.
0 0 to 4294967295
Duration of the link out of
service since last reset.
Field Field Example Range Description
1 Date 2005-11-16 yyyy-mm-dd Date when measurements collected
2 Time 14:40:01 hh:mm:ss Time when measurements collected
3 NOVLD 0 0 to 65535
The number of periods of congestion
(overload) during the measurement period
4 MAXLOAD 380 (3.8%) 0 to 10000
Maximum load average measurement taken
over 1 minute (based on the UNIX load
average) multiplied by 100
5 LOADAVG 164 (1.64%) 0 to 10000
The average load on the system (based on
the UNIX load average) measurement taken
over the measurement period multiplied by
100
6 PERIOD 9062 0 to 4294967295 Duration of measurement period in seconds
