Dialogic ® SS7G2x Signaling Server SGW Mode User Manual Issue 4
9.4.2 Ethernet Port Measurements File Format
2005-11-16,14:40:01,1,265,2016,0,0,0,0,0,0,119,1136,0,0,0,0,0,0,2077
2005-11-16,14:40:01,4,4664602,3448084,0,0,0,0,0,0,1183455,1809415,0,0,0,0,0,0,2077
2005-11-16,14:45:01,1,301,2368,0,0,0,0,0,0,145,1379,0,0,0,0,0,0,2377
2005-11-16,14:45:01,4,10220775,7212808,0,0,0,0,0,0,1270164,3077831,0,0,0,0,0,0,2377
9.4.3 PCM Measurements File Format
2001-12-31,13:07:25,600,1-1,5,50,20,500
2001-01-01,01:01:00,86400,1-2,90,1000,1000,1000
2001-11-22,19:07:38,3600,2-1,1,0,0,0
Field Field Example Range Description
1 Date 2005-11-16 yyyy-mm-dd Date when measurements collected
2 Time 14:40:01 hh:mm:ss Time when measurements collected
3 ETH 1 1 to 4 Ethernet port number
4 RXKBYTE 10220775 0 to 4294967295
Number of kilobytes of data received
(in kilobytes)
5 RXPKT 7212808 0 to 4294967295 Number of packets of data received
6 RXERR 0 0 to 4294967295 Number of receive errors detected
7 RXDROP 0 0 to 4294967295
Number of received packets dropped by the
device driver
8 RXFIFO 0 0 to 4294967295 The number of FIFO buffer errors received
9 RXFRAME 0 0 to 4294967295
The number of packet framing errors
received
10 RXCOMP 0 0 to 4294967295 The number of compressed packets received
11 RXMULT 0 0 to 4294967295 The number of multicast frames received
12 TXKBYTE 1270164 0 to 4294967295
Number of kilobytes of data transmitted
(in kilobytes)
13 TXPKT 3077831 0 to 4294967295 Number of packets of data transmitted
Field Title Example Range Description
1 Date 2001-12-31 yyyy-mm-dd
Date when measurements
collected
2 Time 13:07:25 hh:mm:ss
Time when measurements
collected
3 Period 600 0:4294967295
Duration of measurement
period in seconds
4 PCM 3-1
x: 1 to 3
y: 1 to 4
PCM: x-y
board id – port id.
5 Frame Slip counter 50 0 to 4294967295
Number of frame slips
occurred.
6
Out of synchronism
transitions
1000 0 to 4294967295
Number of out-sync
transitions.
7
Errored Seconds
counter
20 0 to 4294967295
Number of Errored Seconds
occurred.
8
Severely Errored
Seconds counter
500 0 to 4294967295
Number of Severely Errored
Seconds.
