154
Chapter 9 Remote Data Centre Operation
9.4.4 SS7 Link Measurements File Format
2001-12-31,13:07:25,600,3,1000,56,513,502,20,6512,6502,10
2001-01-01,01:01:00,86400,2,5000,10,1000,1000,10,1000,1000,0
2001-11-22,19:07:38,3600,1,0,0,0,0,0,0,0,0
Field Title Example Range Description
1 Date 2001-12-31 yyyy-mm-dd
Date when measurements
collected
2 Time 13:07:25 hh:mm:ss
Time when measurements
collected
3 Period 600 0 to 4294967295
Duration of measurement
period in seconds
4 SS7 Link 3 0 to 32 SS7 Link Number.
5 In Service 1000 0 to 4294967295
Duration of the link IN-
SERVICE state.
6 Negative ACK 56 0 to 4294967295
Number of negative
acknowledgement received.
NOTE: Not applicable for
M2PA SS7 links and
is set to 0. See
SIGTRAN Link
measurements.
7 Octects Transmitted 513 0 to 4294967295
Number of octetcs
transmitted.
8 Octects Received 502 0 to 4294967295 Number of octetcs received.
9
Octets
Retransmitted
20 0 to 4294967295
Number of octetcs
retransmitted.
NOTE: Not applicable for
M2PA SS7 links and
is set to 0. See
SIGTRAN Link
measurements.
10 MSU Transmitted 6512 0 to 4294967295
Number of MSU
transmitted.
11 MSU Received 6502 0 to 4294967295 Number of MSU received.
12 Congestion Counter 10 0 to 4294967295
Number of congestion
events occurred.
