30
Chapter 5 Parameter Definitions
Chapter 5: Parameter Definitions
5.1 Parameter Table
Table 2 lists all parameters and details the possible values.
All numeric parameters are entered and output in decimal notation.
is either , , , $, or -. The use of quotation
marks to delimit text strings is not required.
Table 2. Parameter Definitions
Name Description Range Notes
ALP
Sequential reference number of an entry in
the Alarm Log
1 to 9999
AS
Logical reference for a SIGTRAN Application
Server
1 to 200
BCIC
The circuit identification code of an SS7
circuit that is the base CIC of a CIC Range
0 to 4095
BPOS
Board position number (for signaling
boards)
1 to 3
BRDTYPE
Board type descriptor, in the format:
xxxxxx-y-z
where:
• xxxxxx = board type
• y = number of signaling links
configured on the board
• z = number of PCM ports on the board
See Section 5.4, “Board Types” on page 39 .
One of the following:
• SPCI2S-4-2
• SPCI2S-8-2
• SPCI4-4-4
• SPCI4-8-4
• SS7HDP-64-4
BUILDOUT
The buildout type:
• 0 - Setting for E1 devices.
• 1 - T1 short haul 0 - 110 ft.
• 2 - T1 short haul 0 - 110 ft.
• 3 - T1 short haul 110 - 220 ft.
• 4 - T1 short haul 220 - 330 ft.
• 5 - T1 short haul 330 - 440 ft.
• 6 - T1 short haul 440 - 550 ft.
• 7 - T1 short haul 550 - 660 ft.
• 8 - T1 long haul LB0 (-0dB)
• 9 - T1 long haul LB0 (-7.5dB)
• 10 - T1 long haul LB0 (-15dB)
• 11 - T1 long haul LB0 (0dB TR62411)
0 to 11
Default =
• 0 for E1
• 1 for T1
C7LINK Logical reference for an SS7 signaling link 1 to 128
C7RT Logical reference of an SS7 route 1 to 128
CLA
Alarm class number. One of:
• 0 = Unreported (the alarm is logged,
but it does not trigger an alarm relay
and is not included in SNMP output.
• 1 = Minor (triggering the MNR alarm
LED and relay)
• 2 = Major (triggering the MJR alarm
LED and relay)
• 3 = Critical (triggering the CRT alarm
LED and relay)
0 to 3
CODE Fault code of a system alarm 1 to 256
CONFIRM
Confirmation of a password used to provide
password control access to MML
0 to 12
character>
CRTYPE
The type of continuous record:
• ALARM – alarms that have been
reported to the alarm log
ALARM
