YSI 5200A

Notes:

- When DHCP is enabled, the 5200A IP address is not updated at the IP

address menu.

- When DHCP is enabled, the serial to ethernet device acquires SMTP and

DNS addresses during initialization.

- AquaManager requires a static IP address; therefore, DHCP must be

disabled when using AquaManager. Consult the network administrator

to obtain a static IP address.

- Power cycle the 5200A whenever DHCP is enabled.

IP Address

Menus → System → Communications → Ethernet → IP Address

The IP address can only be configured when DHCP is disabled.

Notes:

- AquaManager users should program the Gateway address either by force

serial port in the AquaManager Communication menu or locally at the

5200A. Poll node using RS232 communication to upload configuration

information including: static IP, port, subnet, and gateway addresses.

- When DHCP is enabled, the IP address is not updated at the IP address

menu.

- Power cycle the 5200A whenever a new IP address is configured.

- Numbers between 0-255 are valid for each of the four (4) IP Address fields.

Subnet Mask

Menus → System → Communications → Ethernet → Subnet Mask

A Subnet mask address can only be configured when DHCP is disabled. The subnet

mask number helps to define the relationship between the host (computers, rout-

ers, switches, etc.) and the rest of the network. Consult the network administrator

when configuring this menu.

Notes:

- When DHCP is enabled, the Subnet Mask address is not updated at the

Subnet Mask menu.

- AquaManager users should program the Subnet mask either by force

serial port in the AquaManager Communication menu or locally at the

5200A. Poll node using RS232 communication to upload configuration

information including: static IP, port, subnet, and gateway addresses.

- Numbers between 0-255 are valid for each of the four (4) Subnet Mask

IP Address fields.

Configuring the 5200A

Gateway

Menus → System → Communications → Ethernet → Gateway

The Gateway address can only be configured when DHCP is disabled. A gateway IP

refers to a device on a network which sends local network traffic to other networks.

Consult the network administrator when configuring this menu.

Notes:

- When DHCP is enabled, the Gateway address is not updated at the

Gateway menu.

- AquaManager users should program the Gateway address either by force

serial port in the AquaManager Communication menu or locally at the

5200A. Poll node using RS232 communication to upload configuration

information including: static IP, port, subnet, and gateway addresses.

- Numbers between 0-255 are valid for each of the four (4) Gateway IP

Address fields

Port

Menus → System → Communications → Ethernet → Port

The default port number for the ethernet module is 10001. Consult the network

administrator when configuring this menu.

Note:

- AquaManager users should program the port number either by force

serial port in the AquaManager Communication menu or locally at the

5200A. Poll node using RS232 communication to upload configuration

information including: static IP, port, subnet, and gateway addresses.

DNS Address

Menus → System → Communications → Ethernet → DNS

Domain Name Service (DNS) numbers are IP addresses that a workstation or server

uses to refer to specific servers that resolve domain names to IP addresses.

Notes:

- When DHCP is enabled, the serial to ethernet device will acquire SMTP

and DNS addresses during initialization.

- When DHCP is enabled, the DNS address is not updated at the IP ad-

dress menu.

- Numbers between 0-255 are valid for each of the four (4) DNS IP Ad-

dress fields
