Appendix 5 Parts and Accessories
Replacement Part Part Number and Description
5561 probe/cable assemblies
cable lengths available: 4m, 10m, 20m, or 30m
p/n 5561 - Includes DO and temperature
sensors
5562 probe/cable assemblies
cable lengths available: 4m, 10m, or 20m)
p/n 5562 - Includes DO, temperature and
conductivity sensors. pH or pH/ORP sen-
sor ordered separately.
Calibration Solutions
Conductivity
For measurement range of:
Solution conductivity value; YSI part number
(p/n); volume
195-1950 µS 1000 µS; p/n 065270; (1) quart or
1000 µS; p/n 060907; (8) 1 pint bottles.
1.95mS-19.5mS 10mS; p/n 065272; (1) quart or
10mS; p/n 060911; (8) 1 pint bottles.
19.5mS-200mS 50mS; p/n 060660; (8) 1 pint bottles or
100mS; p/n 065274; 1 quart
pH pH buffer 4.00 solution: p/n 003821, (6) 1 pint
bottles
pH buffer 7.00 solution: p/n 003822, (6) 1 pint
bottles
pH buffer 10.00 solution: p/n 003823, (6) 1
pint bottles
Assorted buffer case: p/n 603824, (2) 1 pint
bottles of buffer 4, (2) 1 pint bottles of buffer
7, and (2) 1 pint bottles of buffer 10.
DO Membranes
2 mil PE (blue)
605307 membrane kit contains:
-6 cap membranes
-Probe electrolyte
-sanding disk
-3 gaskets
Parts & Accessories
Replacement Part Part Number and Description
2 mil TE (gray) 605204 membrane kit contains:
-6 cap membranes
-Probe electrolyte
-sanding disk
-3 gaskets
ORP Zobell Solution: p/n 061320, 125 mL.
Installation Mounting kits
Panel mount kit
006510 - for mounting 5200A instrument to
a panel.
Probe mount kit 655357 - for mounting 5562 probe/cable as-
sembly in a 2 inch PVC pipe. Includes stop
cap and adapter.
Probe mount kit 006511 - for mounting 5562 probe/cable
assembly in a 2 inch pipe. Includes stop cap,
adapter, brackets and u-bolts for securing pipe
to a rail.
Rail mount kit 006509 - for mounting a 5200A instrument to
a rail.
Weather shield kit 006505
Port Plugs (5562 only)
DO sensor port
605268 (can also be used on 5561)
pH sensor port 605252
pH/ORP sensor port 605252
Conductivity/temperature sensor port 605252
Sensors
DO, Polarographic
655900
pH 005564 (5562 cable only)
pH/ORP 005565 (5562 cable only)
Conductivity/temperature 005560 (5562 cable only)
Other
AC Power cord, 115 VAC, USA plug
605880, for AC version only, included with
AC version
Adapter, DB-9 to RJ-45 655383, included with instrument
AquaManager Software, single and
network use
655363
