2.7.5 J4, 5 : Expansion Header
Provide most function of eddy-S4M with pin connector.
You can confirm the function with direct conjunction to Eddy-S4M-DK
.
J4 J5
Pin Signal Pin Signal Pin Signal Pin Signal
1 DTxD 2 DRxD 1 LAN_RX+ 2 LAN_TX+
3 TxD0# 4 RxD0# 3 LAN_RX- 4 LAN_TX-
5 RTS0 6 CTS0 5 LAN_Speed 6 LAN_LINK
7 DTR0 8 DSR0 7 PA5 8 PA22
9 DCD0 10 RI0 9 PA30 10 NC
11 TxD1# 12 RxD1# 11 PB0 12 PB1
13 RTS1 14 CTS1 13 PB2 14 PB3
15 3.3V 16 3.3V 15 5V 16 5V
17 P3_TX+ 18 P3_TX- 17 PB12 18 PB13
19 P3_RX+ 20 P3_RX- 19 PB16 20 PB17
21 P4_TX+ 22 P4_TX- 21 PB18 22 PB19
23 P4_RX+ 24 P4_RX- 23 PB20 24 PB21
25 DDM 26 DDP 25 PB30 26 PB31
27 DM2 28 DP2 27 PC0 28 PC1
29 DM3 30 DP3 29 PC2 30 PC3
31 GND 32 GND 31 GND 32 GND
33 DM4 34 DP4 33 PC5 34 PC9
35 SDDATA0 36 SDDATA1 35 PC10 36 PC12
37 SDDATA2 38 SDDATA3 37 PC13 38 PC14
39 SDCMD 40 SDCLK 39 PC15 40 PC17
41 SDCDN 42 SDWP 41 PC18 42 PC19
43 TWCK 44 TWD 43 PC20 44 PC24
45 RDY# 46 nRESET(IN) 45 PC25 46 NRST(OUT)
