Table 16. Electrical Data.
SINGLE PHASE MODELS
MODEL
NUMBER
R8HE / PPG3HE
HEATING
INPUT
(BTUH)
INDUCER
MOTOR
NOMINAL
ELECTRICAL
SUPPLY
VOLTAGE
RANGE
COMPRESSOR
FAN
AMPS
BLOWER
MOTOR
AMPS
MINIMUM
CIRCUIT
AMPACITY
MAXIMUM
OVER-
CURRENT
PROTECTION
RLA
MIN.
MAX.
RLA
LRA
X24K060XA
HIGH - 60,000
0.30
208/230-1-60 187
253
12.8
58
1.0
5.4
22.4
35
LOW - 39,000
X30K060XA
HIGH - 60,000
0.30
208/230-1-60 187
253
15.7
73
1.5
5.4
26.5
40
LOW - 39,000
X36K080XA
HIGH - 80,000
0.30
208/230-1-60 187
253
18.6
79
1.5
7.0
31.8
50
LOW - 52,000
X42K080XA
HIGH - 80,000
0.30
208/230-1-60 187
253
22.1
109
1.5
7.0
36.1
55
LOW - 52,000
X48K096XA
HIGH - 96,000
0.30
208/230-1-60 187
253
24.3
117
1.5
7.0
38.8
60
LOW - 62,400
X60K096XA
HIGH - 96,000
0.30
208/230-1-60 187
253
29.4
134
1.5
7.0
45.2
70
LOW - 62,400
THREE PHASE MODELS
MODEL
NUMBER
R8HE / PPG3HE
HEATING
INPUT
(BTUH)
INDUCER
MOTOR
NOMINAL
ELECTRICAL
SUPPLY
VOLTAGE
RANGE
COMPRESSOR
FAN
AMPS
BLOWER
MOTOR
AMPS
MINIMUM
CIRCUIT
AMPACITY
MAXIMUM
OVER-
CURRENT
PROTECTION
RLA
MIN.
MAX.
RLA
LRA
R8HE-X36C080X
HIGH - 80,000
0.30
208/230-3-60 187
253
11.6
73
1.5
7.0
23.0
30
LOW - 52,000
R8HE-X36D080X
HIGH - 80,000
0.30
460-3-60
414
506
6.4
38
0.6
3.3
11.9
15
LOW - 52,000
R8HE-X48C096X
HIGH - 96,000
0.30
208/230-3-60 187
253
15.3
83
1.5
7.0
27.6
40
LOW - 62,400
R8HE-X48D096X
HIGH - 96,000
0.30
460-3-60
414
506
6.9
41
0.6
3.3
12.5
15
LOW - 62,400
R8HE-X60C096X
HIGH - 96,000
0.30
208/230-3-60 187
253
17.8
110
1.5
7.0
30.7
45
LOW - 62,400
R8HE-X60D096X
HIGH - 96,000
0.30
460-3-60
414
506
8.6
52
0.6
3.3
14.7
20
LOW - 62,400
NOTES: LRA = Locked Rotor Amps; RLA = Rated Load Amps
Electrical Data
COPPER WIRE SIZE — AWG
(1% VOLTAGE DROP)
SUPPLY WIRE LENGTH-FEET
SUPPLY CIRCUIT
AMPACITY
200
150
100
50
6
8
10
14
15
4
6
8
12
20
4
6
8
10
25
4
4
6
10
30
3
4
6
8
35
3
4
6
8
40
2
3
4
6
45
2
3
4
6
50
2
3
4
6
55
1
2
3
4
60
NOTE: Wire Size based on N.E.C. for 60° type copper conductors.
Table 17. Copper Wire Size
Table 18. Thermostat Wire Gauge
THERMOSTAT
WIRE GAUGE
RECOMMENDED T-STAT WIRE
LENGTH (UNIT TO T-STAT)
2-WIRE
(HEATING)
5-WIRE
(HEATING / COOLING)
24
55
25
22
90
45
20
140
70
18
225
110
