Chapter 5: Local Management
5-40 6H122-08 User’s Guide
5.15 GENERAL CONFIGURATION SCREEN
The General Configuration screen, Figure 5-18 , allows the user to set the
system date and time, IP address and subnet mask, the default gateway,
the TFTP Gateway IP address, the Operational Mode, the Management
Mode, and the COM port configuration. The General Configuration
screen also allows the user to Clear NVRAM, and enable or disable IP
Fragmentation.
Access the General Configuration screen from the Module Configuration
Menu screen by using the arrow keys to highlight the GENERAL
CONFIGURATION menu item and pressing ENTER. The General
Configuration screen,
Figure 5-18 , displays.
Figure 5-18 General Configuration Screen
The following briefly explains each General Configuration screen field:
MAC Address (Read-Only)
Displays the base physical address of the module.
Firmware Revision: XX.XX.XX
General Configuration
2159_16
BOOTPROM Revision: XX.XX.XX
MAC Address:
IP Address:
Subnet Mask:
Default Gateway:
TFTP Gateway IP Addr:
Module Date:
Module Time:
Screen Refresh Time:
Screen Lockout Time:
Com: [ENABLED] Application: [LM]
Clear NVRAM [NO]
Module Uptime XX D XX H XX M
Module Type: 6H122-08
Slot Number: X
IP Fragmentation [ENABLED]
Operational Mode: [802.1D SWITCHING] Management Mode: [DISTRIBUTED]
00-00-ID-00-00-00
0.0.0.0
255.255.0.0
NONE DEFINED
0.0.0.0
6H122-08 LOCAL MANAGEMENT
Event Message Line
RETURN SAVE
10/11/97
14:23:00
30 sec.
15 min.
EXIT
