Chapter 5: Local Management
5-84 6H122-08 User’s Guide
Figure 5-31 Module Statistics Menu Screen
The Module Statistics Menu screen displays the following menu items:
SWITCH STATISTICS
The Switch Statistics screen lists the number of frames received,
transmitted, filtered, and forwarded by each interface.
INTERFACE STATISTICS
The Interface Statistics screen provides the MIB-II statistics for each
switched interface, on an interface-by-interface basis.
RMON STATISTICS
The RMON Statistics screen displays all the statistics gathered by the
embedded RMON agent built-in to the 6H122-08.
Firmware Revision: XX.XX.XX
Module Statistics Menu
SWITCH STATISTICS
INTERFACE STATISTICS
RMON STATISTICS
2159-27
BOOTPROM Revision: XX.XX.XX
6H122-08 LOCAL MANAGEMENT
Module Type: 6H122-08
Slot Number: X
RETURN EXIT
