6H122-08 User’s Guide 3-1
CHAPTER 3
INSTALLATION
This chapter covers the following items:
• Unpacking the 6H122-08 ( Section 3.2 )
• Installing options ( Section 3.3 )
• Installing the 6H122-08 into the 6C105 chassis ( Section 3.4 ).
• Connecting to the network ( Section 3.5 )
• Completing the installation ( Section 3.6 )
3.1 REQUIRED TOOLS
A Phillips screwdriver is required to install the Fast Ethernet Interface
Modules in the 6H122-08.
3.2 UNPACKING THE 6H122-08
1. Open the box and remove the packing material protecting the module.
2. Verify the contents of the carton as listed in Table 3-1 .
Only qualified personnel should install the 6H122-08.
Table 3-1 Contents of 6H122-08 Carton
Item Quantity
6H122-08 1
Manual Accessory Kit 1
