Port Redirect Function Screen

6H122-08 User’s Guide

5-79

Access the Port Redirect Function screen from the Module Specific
Configuration Menu screen by using the arrow keys to highlight the
PORT REDIRECT FUNCTION menu item and pressing ENTER. The
Port Redirect Function

screen displays.

Figure 5-29

Port Redirect Function Screen

The following definitions briefly explain each field of the Port Redirect
Function screen:

Source Port (Read-only)

Shows which ports are currently set as source ports.

Destination Port (Read-only)

Shows which ports are currently set as destination ports.

Remap Errors (Read-only)

Displays whether the corresponding source ports are configured to send
errored frames to the destination ports, or to drop all errored frames
before forwarding traffic.

Source Port [

n] (Selectable)

Allows a selected port [n] to be changed to a source port.

Destination Port [

n] (Selectable)

Allows a selected port [n] to be changed to a destination port.

Firmware Revision: XX.XX.XX

Port Redirect Function

2159_26

BOOTPROM Revision: XX.XX.XX

Source Port:

1

2

1

Destination Port:

5

6

6

Module Type: 6H122-08

Slot Number:

X

Remap Errors:

ON

ON

OFF

============

============

============

6H122-08 LOCAL MANAGEMENT

Event Message Line

SAVE

RETURN

RETURN

Source Port [1]

Destination Port [1]

Status [ADD]

EXIT

Errors [ON]
