The Interface Statistics Screen
6H122-08 User’s Guide 5-87
5.27 THE INTERFACE STATISTICS SCREEN
The Interface Statistics screen is used to gather MIB-II statistics for all of
the 6H122-08 interfaces (ports 1 through 6, optional Fast Ethernet
Interface Modules and all backplane interfaces).
Access the Interface Statistics screen by using the arrow keys to highlight
the INTERFACE STATISTICS menu item on the Module Statistics
Menu screen and pressing ENTER. The Interface Statistics screen,
Figure 5-33 , displays.
Figure 5-33 Interface Statistics Screen
The following definitions explain each field of the Interface Statistics
screen:
Interface (Read-only)
This field displays the Interface number for which statistics are currently
being displayed.
Figure 5-33 shows the Interface field displaying 1. This
represents ENET 1 of the module. To view other interface statistics, refer
to
Section 5.27.1 .
