Chapter 5: Local Management
5-34 6H122-08 User’s Guide
5.12 MODULE SELECTION SCREEN
The Module Selection screen is the access point to Local Management for
all modules installed in the SmartSwitch 6000 chassis. By selecting a
module, the Module Menu for the selected device displays.
Figure 5-15
shows the Module Selection screen.
Figure 5-15 Module Selection Screen
The following explains each Module Selection screen field as shown in
Figure 5-15 .
Module # (Selectable)
The Module # field displays the slot in which the module is installed. The
module number enclosed in < > characters indicates the module to which
the management terminal or Telnet session is connected.
Module Type (Read-only)
The Module Type field displays the type of interface module that is
installed in each slot.
Module Selection
2159-39
EXIT
Module #
<1>
2
3
4
5
Module Type
6H122-08
6E132-25
6E123-26
6E122-26
Serial #
123456789
123456789
123456789
123456789
Hardware Revision
XXX
XXX
XXX
XXX
6H122-08 LOCAL MANAGEMENT
RETURN
