Chapter 5: Local Management
5-64 6H122-08 User’s Guide
5.19 ETHERNET INTERFACE CONFIGURATION
Access the Ethernet Interface Configuration screen from the Module
Specific Configuration Menu screen by using the arrow keys to highlight
the ETHERNET INTERFACE CONFIGURATION menu item and
pressing ENTER. The Ethernet Interface Configuration
screen displays.
Figure 5-25 Ethernet Interface Configuration Screen for the 6H122-08
The following section briefly explains each field of the Ethernet Interface
Configuration screen:
Port Num (Read-Only)
Displays the number of the front panel interface.
Port Type (Read-Only)
Displays the name of the interface installed in ports 1 through 8.
