Module Specific Configuration Menu Screen
6H122-08 User’s Guide
5-71
BROADCAST SUPPRESSION
The Broadcast Suppression screen allows the user to set a desired limit of
receive broadcast frames per port per second. For details, refer to
.
802.1Q VLAN CONFIGURATION
This menu item will only display if the module has been configured to
operate as an IEEE 802.1Q switch and the Management Mode has been
set to STAND ALONE. When selected, this menu item opens the VLAN
Main Menu screen. For details, refer to the Cabletron Systems Port Based
VLAN User’s Guide.
,
describes how to configure the modules to function as 802.1Q switches.
, describes how to set
the module to STAND ALONE management mode.
NOTE
The module does not have to be in STAND ALONE mode to
operate as an 802.1Q switch. In DISTRIBUTED management
mode, 802.1Q VLANs are created and maintained via the
802.1Q VLAN CONFIGURATION menu item on the Chassis
Menu screen. Refer to
for details.
