Chapter 5: Local Management
5-70 6H122-08 User’s Guide
Figure 5-26 Module Specific Configuration Menu Screen
The following explains each field of the Module Specific Configuration
Menu screen:
SYSTEM RESOURCES
The System Resources screen displays the amount of FLASH memory,
DRAM, and NVRAM installed, details how much memory is available
and provides information on 6H122-08 operation. For details, refer to
Section 5.21 .
FLASH DOWNLOAD
The FLASH Download screen allows the user to force the 6H122-08 to
download a new image file to FLASH memory from a TFTP server. For
details, refer to
Section 5.22 .
PORT REDIRECT FUNCTION
The Port Redirect Function screen allows the user to redirect traffic from
one or more ports on the module to a specific destination port on the
module. For details, refer to
Section 5.23 .
Firmware Revision: XX.XX.XX
Module Specific Configuration Menu
SYSTEM RESOURCES
FLASH DOWNLOAD
PORT REDIRECT FUNCTION
BROADCAST SUPPRESSION
802.1Q VLAN CONFIGURATION
2159-21
BOOTPROM Revision: XX.XX.XX
Module Type: 6H122-08
Slot Number: X
EXIT RETURN
6H122-08 LOCAL MANAGEMENT
SAVE
