Chapter 5: Local Management
5-36 6H122-08 User’s Guide
5.13 MODULE MENU SCREEN
The Module Menu screen is the access point for all Local Management
screens for the 6H122-08.
Figure 5-16 shows the 6H122-08 Module
Menu screen.
Figure 5-16 Module Menu Screen
The following explains each Module Menu screen field as shown in
Figure 5-16 :
MODULE CONFIGURATION
The Module Configuration screen provides access to the Local
Management screens that are used to configure the 6H122-08. The
Module Specific Configuration Menu screen provides access to the
screens that allow the user to check 6H122-08 resources and set operating
parameters specific to each port. For details about the Module
Configuration Menu screen, refer to
Section 5.14 . For details about the
Module Specific Configuration Menu screen, refer to Section 5.20 .
Firmware Revision: XX.XX.XX
Module Menu
MODULE CONFIGURATION
2159-14
Module Type: 6H122-08
Slot Number: X BOOTPROM Revision: XX.XX.XX
6H122-08 LOCAL MANAGEMENT
RETURN
MODULE STATISTICS
NETWORK TOOLS
EXIT
