Section c.3 – Cabletron Systems Expansion module 6H122-08 User Manual
Page 162
Appendix C: Optional Installations and Mode Switch Bank Settings
C-4
6H122-08 User’s Guide
C.3
INSTALLING OPTIONAL FAST ETHERNET
INTERFACE MODULES
shows the location of the Fast Ethernet Interface Module
connectors on the 6H122-08 board for port slots 7 and 8.
Figure C-2
6H122-08 Fast Ethernet Interface Module Connector Location
Optional Fast
Ethernet Interface
Modules
Connectors
