Chapter 3: Installation
3-2 6H122-08 User’s Guide
3.3 INSTALLING OPTIONS
If the 6H122-08 will be installed with an optional Fast Ethernet Interface
Module refer to
Appendix C for installation instructions.
3.4 INSTALLING THE 6H122-08 INTO THE 6C105
CHASSIS
The 6H122-08 can be installed in any of the 5 slots that are available. To
install a module, proceed as follows:
1. Remove the blank panel covering the slot in which the module will be
installed. All other slots must remain covered to ensure proper airflow
and cooling. (Save the blank plate in the event you need to remove the
module.)
2. Carefully remove the module from the shipping box. (Save the box
and packing materials in the event the module must be reshipped.)
3. Locate the antistatic wrist strap shipped with the 6C105 chassis.
Attach the antistatic wrist strap to your wrist and plug the cable from
the antistatic wrist strap into the ESD grounding receptacle at the
upper right corner of the 6C105.
NOTE
Install any optional equipment before proceeding to
Section 3.4 .
!
CAUTION
Failure to observe static safety precautions could cause
damage to the 6H122-08. Follow static safety handling rules
and properly wear the antistatic wrist strap provided with the
6C105 chassis.
!
CAUTION
Do not cut the non-conductive bag to remove the module.
Damage could result from sharp objects contacting the board
or components.
