Switch Statistics Screen
6H122-08 User’s Guide 5-85
5.26 SWITCH STATISTICS SCREEN
The Switch Statistics screen, Figure 5-32 , lists the number of frames
received, transmitted, filtered, and forwarded by each interface, including
backplane interfaces.
Access the Switch Statistics screen from the Module Statistics Menu
screen by using the arrow keys to highlight the SWITCH STATISTICS
menu item and pressing ENTER. The Switch Statistics screen displays.
Figure 5-32 Switch Statistics Screen
NOTES
The Switch Statistics screen will not be available if the
operational mode of the module has been set to SECURE
FAST VLAN. This screen may only be used by modules
configured to operate as traditional or 802.1Q switches.
Ports 7 and 8 on the Switch Statistics screen represent the
optional Fast Ethernet Interface Modules available for the
6H122-08.
Ports 9 through 12 represent the backplane connections that
the 6H122-08 has with the 6C105 chassis. The module has a
direct connection to every other slot in the chassis.
Firmware Revision: XX.XX.XX
Switch Statistics
2159-28
BOOTPROM Revision: XX.XX.XX
RETURN
Module Type: 6H122-08
Slot Number: X
6H122-08 LOCAL MANAGEMENT
Event Message Line
Port #
1
2
3
4
5
6
7
8
9
10
11
12
Frames Rcvd
100
100
100
100
100
100
100
100
100
100
100
100
Frames Txmtd
100
100
100
100
100
100
100
100
100
100
100
100
Frames Fltrd
0
0
0
0
0
0
0
0
0
0
0
0
Frames Frwded
100
100
100
100
100
100
100
100
100
100
100
100
EXIT CLEAR COUNTERS
