Chassis Environmental Screen
6H122-08 User’s Guide 5-29
5.10 CHASSIS ENVIRONMENTAL SCREEN
The Chassis Environmental menu item allows the user to view chassis
environmental information.
Access the Chassis Environmental Information screen from the Chassis
Menu screen by using the arrow keys to highlight the CHASSIS
ENVIRONMENTAL menu item and pressing ENTER. The Chassis
Environmental Information screen,
Figure 5-13 , displays.
Figure 5-13 Chassis Environmental Screen
The following describes each of the Chassis Environmental Information
screen fields.
Chassis Power Redundancy (Read-Only)
Displays the current redundancy status of the 6C105 power supplies. This
field will read either “Available” or “Not Available”.
Power Supply # X Status (Read-Only)
Displays the current status of power supplies 1 and 2 for the 6C105. This
field will read either “Normal”, “Fault”, or “Not Installed”.
Chassis Fan Status (Read-Only)
Displays the current status of the 6C105 fan tray. This field will read
either “Normal”, “Fault”, or “Not Installed”.
Chassis Environmental Information
6C105 LOCAL MANAGEMENT
Event Message Line
RETURN
Chassis Power Redundancy
Power Supply #1 Status
Power Supply #2 Status
Chassis Fan Status
Not Available
Normal
Not Installed
Normal
EXIT
