Chapter 5: Local Management
5-74 6H122-08 User’s Guide
5.22 FLASH DOWNLOAD SCREEN
The Flash Download screen, shown in Figure 5-28 , allows the user to
clear the information stored in the 6H122-08 FLASH memory and
download a new image file from a TFTP server.
Before downloading a new image to the module, load the image onto the
network TFTP server.
Access the Flash Download screen from the Module Specific
Configuration screen by using the arrow keys to highlight the FLASH
DOWNLOAD menu item and pressing ENTER. The Flash Download
screen displays.
Figure 5-28 Flash Download Screen
NOTE
The user may also force a download by changing the position
of Switch 6 located inside the module. Refer to
Section C.2 for
details.
NOTE
For information on how to set up a workstation as a TFTP
server, refer to the specific workstation documentation.
Firmware Revision: XX.XX.XX
Flash Download
Download Method:
Reboot After Download:
TFTP Gateway IP Addr:
Last Image Server IP:
Last Image File Name:
Download Server IP:
Download File Name:
2159-24
BOOTPROM Revision: XX.XX.XX
[TFTP]
[YES]
134.141.79.123
134.141.79.121
/tftpboot/6E122.hex
134.141.79.121
/tftpboot/6E122.hex
Module Type: 6H122-08
Slot Number: X
EXIT RETURN
6H122-08 LOCAL MANAGEMENT
TFTP DOWNLOAD. WILL COMMIT TO FLASH. REBOOT IN PROGRESS...
EXECUTE
