Broadcast Suppression Screen
6H122-08 User’s Guide 5-81
5.24 BROADCAST SUPPRESSION SCREEN
The Broadcast Suppression screen, Figure 5-30 , allows the user to set a
desired limit of receive broadcast frames per port per second.
Access the Broadcast Suppression screen from the Module Specific
Configuration screen by using the arrow keys to highlight the
BROADCAST SUPPRESSION menu item and pressing ENTER. The
Broadcast Suppression screen displays.
Figure 5-30 Broadcast Suppression Screen
NOTE
The Broadcast Suppression screen may not be available if the
operational mode of the module has been set to SECURE
FAST VLAN. Refer to your Release Notes to see what
operational modes support Broadcast Suppression. Refer to
Section 5.15.9 for instructions on configuring the operational
mode of the module.
Any broadcast frames received above the desired threshold will
be dropped.
Firmware Revision: XX.XX.XX
Broadcast Suppression
2159-25
BOOTPROM Revision: XX.XX.XX
PORT #
1
2
3
4
5
6
7
8
Time Since Peak
999:23:59
999:23:59
999:23:59
999:23:59
999:23:59
999:23:59
999:23:59
999:23:59
Peak Rate
150000
150000
150000
150000
150000
150000
150000
150000
Threshold
150000
150000
150000
150000
150000
150000
150000
150000
Module Type: 6H122-08
Slot Number: X
6H122-08 LOCAL MANAGEMENT
Event Message Line
Total RX
12345678910
12345678910
12345678910
12345678910
12345678910
12345678910
12345678910
12345678910
Reset Peak
[NO]
[NO]
[NO]
[NO]
[NO]
[NO]
[NO]
[NO]
RETURN SAVE EXIT
