Table 13 — Keyboard Directory (cont)
QUICK TEST
Keyboard Entry Display Description
INPUTS Factory/field test of inputs
SAT X Supply air temperature
OAT X Outside air temperature
SPT X Space temperature
RAT X Return air temperature
ENT X Enthalpy switch status
SFS X Airflow switch status
FRZ X Freezestat
SP X Static pressure
RH X Return air relative humidity
MAT X Mixed air temperature
OARM X Outside air relative humidity
FLTS X Filter status
TEMP X Temperature input
RVP X Return velocity pressure
SVP X Supply velocity pressure
DHH X Duct high humidity
EVAC X Evacuation
PRES X Pressurization
PURG X Smoke purge
FSD X Fire shutdown
MTR X Wattmeter
OAVP X Outside air velocity pressure
AQ1 X Air quality 1
AQ2 X Air quality 2
CUST X Condensing unit status
DXSD X DX cooling shutdown
DX — Direct Expansion
QUICK TEST
Keyboard Entry Display Description
OUTPUTS Factory/field test of outputs
HCV X Entering heating coil valve test
HCV TEST Testing heating coil valve
CCV X Entering cooling coil valve test
CCV TEST Testing cooling coil valve
MIXD X Entering mixed air damper test
MIXD TEST Testing mixed air dampers
IGV X Entering inlet guide vanes test
IGV TEST Testing inlet guide vanes
SF X Entering supply fan test
FAN TEST Testing supply fan
HIR X Entering heat interlock relay test
HIR TEST Testing heating interlock relay
RFVC X Entering return fan volume test
RFVCTEST Testing return fan volume
HUM1 X Entering humidifer stage 1 test
HUM1TEST Testing humidifer stage 1
HUM2 X Entering humidifier stage 2 test
HUM2TEST Testing humidifier stage 2
AOTC X
Entering analog temperature control
output test
AOTCTEST
Testing analog temperature control
output
DOTC X
Entering discrete temperature control
output test
DOTCTEST
Testing discrete temperature control
output
DTCC X
Entering discrete time clock control
output test
DTCCTEST
Testing discrete time clock control
output
