0 LandMark Mobile User’s Manual
Introduction and Operation
After LandMark Mobile is installed, you can operate it in the
field or office. This chapter describes the operation, screens, and
specific features of the program.
To begin using LandMark Mobile, from the Today screen
select Start | Programs | LandMark Mobile icon. A splash screen
displaying LandMark Mobile A GPS Receiver Utility and the version
number are displayed for two seconds. The program opens to one
the following two screens.
The left screen is typical of a portrait display on the Archer Field
PC while the screen on the right is typical of a landscape display
on the Allegro MX.
Screen Selection
The initial program screen allows you to select between the
different operations that LandMark Mobile offers.
Menu = Drop Down Menu
= Waypoint Screen
= GPS Screen
= Connect
= Navigation Screen
= Mark
= Configuration Screen
Note: The program can be used in landscape or portrait mode. The
information will be the same but the screen layout varies.
