92
F
u
nction
(Opening Screen)
MENU 1
Press t he button
Calling the setup screen
(Opening Screen)
MENU 2
DIRECT SEL
*Calling from menu screen
Press the button set
at this function.
MENU1/2 selection
by
button
Menu screen call
by
button
Select the function
by
button
Press t he button
* When the direct call button is set,
the setup screen is also called by the
following method:
Model Name "NAME"
*The character at the blink -
ing cursor position can be
changed. The model name and
user name can both use up to
10 characters.
When a character is entered by
pressing the (JOG) button, the
model name and user name
cursors move to the right.
User name
Model name
Select the character with the
(JOG) button. The selected char-
acter blinks.
1
(Moving the cursor to the character you want to change)
Move the cursor to the model name or user name character
you want to set or change by pressing the (+) or (-) button.
The selected character blinks.
2
(Selecting the character to be used)
Select the character to be used from the character list at the
right-hand side of the screen by (JOG) button up, down, left,
or right operation. The selected character blinks. After select-
ing the character to be used, press the (JOG) button. The
character is entered and the model name or user name char-
acter row moves to the right.
When "RESET" on the top row of the character list is select-
ed and the (JOG) button is pressed, the model name or user
name is initialized to the factory setting.
3
When ending setting, return to the initial screen by pressing
the (END) button twice (for direct selection, press the (END)
button once).
Setting the model name and user name
Character select/set button
- Select the character by (JOG)
button up, down, left, or right
operation and enter the char-
acter by pressing the (JOG)
button.
Initialization
Model name :MODEL-M(No)
User name
:FUTABA-3PK
Model Name "NAME"
This function allows you to assign a ten character name to each model memory and an
user name (ten character).
