Page 22

Using

Total timer display (H:M)

Battery voltage display

Steering trim display

Throttle trim display

DL1
DL2
DL3
DT1
DT2
DT3

User name display

When the (END) button is held down for 1 second or longer at the initial screen, the

Futaba logo and user name are displayed for about 2 seconds.

Edit button lock display

Trim/dial lock display

Power switch turned on

Beep conﬁrmation sound is generated and the
initial screen shown below appears.

Display when power switch turned on

*Function names and rate

assigned to dials are dis-
played.

* D i s p l a y m o d e c a n b e

changed by using the SYS-
TEM function. (See pge 98)

Model name (10 characters)

Edit button lock and trim/dial lock

T3PKS setup and operation by edit button (p.15) and digital trim DT1, DT2, and DT3
and dials DL1, DL2, and DL3 can be prohibited.

Setting

Edit button lock; When the (+) button is pressed for about 1 second at the initial screen,

a conﬁrmation beep is generated and the edit button lock display

appears on the

screen.

Trim/dial lock; When the (-) button is pressed for about 1 second at the initial screen,

a conﬁrmation beep is generated and the trim/dial lock display

appears on the

screen.

Clearing

Edit button lock and trim/dial lock can be cleared in the initial screen state by the same

method as setting described above. (The edit button lock display

or trim/dial lock

display

disappears from the screen.)

Displays whether or not a memory
module is inserted. When a memory
module is inserted, "DPAC" is dis-
played.

"BLHT" is displayed when back-
lighting is ON.

When radio waves are being
emitted, "RF" is displayed. When
radio waves are not being emitted
when turned on by display switch
and when the DSC function is
used, "DISP" is displayed.

Displays whether or not a
memory module is inserted.
When a memory module is
inserted, "DPAC" is displayed.
