+1% ~ +100%
-1% ~ -100%
Ser
v
o tr
a
v
el
Wheel operation
Quick Mild
Wheel operation
52
(Opening Screen)
MENU 1
Press t he button
Calling the setup screen
(Opening Screen)
MENU 2
DIRECT SEL
*Calling from menu screen
Press the button set
at this function.
MENU1/2 selection
by
button
Menu screen call
by
button
Select the function
by
button
Press t he button
* When the direct call button is set,
the setup screen is also called by the
following method:
F
u
nction
Setup item
RATE: Steering EXP rate
Ver tical cursor moves in step
with steering wheel operation.
Steering EXP "STEXP"
Steering EXP "STEXP" (Steering system)
This function is used to change the sensitivity of the steering servo around the neutral
position. It has no effect on the maximum servo travel.
1
When you want to quicken steering operation, use the (+)
button to adjust the + side. When you want to make steering
operation milder, use the (-) button to adjust the - side.
2
When ending setting, return to the initial screen by pressing
the (END) button twice (for direct selection, press the (END)
button once).
Steering EXP adjustment
When the setting is not determined, or the characteristics of the model are unknown,
start with 0%. (When EXP is set to 0%, servo movement is linear.)
Racers Tip
The steering EXP adujustment (RATE)
can be controlled with with digital dial
DL1, DL2, DL3 or digital trim DT3
etc. with the function select dial func-
tion. (See page 80)
Dial / Trim Setting
Adjustment range
-100~0~+100%
Adjust button
Adjust with the (+) and (-) but-
tons.
- Return to the initial value "0" by
pressing the (+) and (-) buttons
simultaneously for about 1 sec-
ond.
