3rd channel Brake
49
F
u
nction
Throttle Acceleration "ACCEL"
(Preparation)
- Select the setting item "FWRD" by (JOG) button up or down
operation and make the following adjustments:
1
(Forward acceleration amount adjustment)
Use the (+) and (-) buttons to adjust the acceleration amount.
"0" :No acceleration
"100" :Maximum acceleration (Approximately 1/2 of the forward side
steering angle)
2
(Brake side acceleration amount adjustment)
Select the setting item "BRAK" by (JOG) button up or down
operation and use the (+) and (-) buttons to adjust the accel-
eration amount.
"0" :No acceleration
"100" :Maximum acceleration (Brake side maximum steering angle)
3
(3rd channel brake side acceleration amount adjustment)
If the Brake Mixing is being set, the 3rd channel brake side
acceleration will become adjustable.
Select the setting item"BRAK (3CH)" by (JOG) button up or
down operation and adjust acceleration amount by (+) or (-)
button.
"0" :No acceleration
"100" :Maximum acceleration (Brake side maximum steering angle)
4
When ending setting, return to the initial screen by pressing
the (END) button twice (for direct selection, press the (END)
button once).
Throttle acceleration adjustment
The throttle acceleration adujustment amount (FOWRD) , (BRAKE) and 3rd channel
(BRAKE) can be controlled with digital dial DL1, DL2, DL3 or digital trim DT3 etc.
with the function select dial function. (See page 80)
Dial / Trim Setting
Adjust button
Adjust with the (+) and (-) but-
tons.
- Return to the initial value "0" by
pressing the (+) and (-) buttons
simultaneously for about 1 sec-
ond.
Forward acceleration amount
(FWRD)
0~100
Initial value: 0
Brake side acceleration amount
(BRAK)
0~100
Initial value: 0
3rd channel brake side
acceleration amount
(BRAK 3CH)
0~100
Initial value: 0
When " TRG-BRK " is set to " CUT OFF " by boat mode function (p.72), the brake side
function is not activated.
Caution
