Futaba 3PKS - Manual (Page 75)

75
F
u
nction
(Opening Screen)
MENU 1
Press t he button
Calling the setup screen
(Opening Screen)
MENU 2
DIRECT SEL
*Calling from menu screen
Press the button set
at this function.
MENU1/2 selection
by
button
Menu screen call
by
button
Select the function
by
button
Press t he button
* When the direct call button is set,
the setup screen is also called by the
following method:
Idle-Up "IDLUP"
Idle-Up on/off state.
(Preparation)
- Use the function select switch function to select the switch.
1
(Idle-Up rate)
Use the (+) and (-) buttons to set the Idle-Up rate.
2
When ending setting, return to the initial screen by pressing
the (END) button twice (for direct selection, press the (END)
button once).
Idle-Up function adjustment
Use this function to improve the starting characteristics of the engine by raising the
idling speed when starting the engine of a gas powered car.
Offsets the throttle neutral position to the forward side or brake side.
Operation
Select the idle-up function ON/OFF switch with the function select switch function. (See
page 79)
Switch Setting
The LED blinks while the Idle-Up
function is on.
Warning display
While this function is ON, the LED blinks. (When LED is ac-
tive)
also appears on the initial screen and menu screen.If
the power switch is turned on while the idle-up switch is on, an
audible alarm will be heard. Immediately set the Idle-Up switch
to OFF.
Operation Display
Idle-Up "IDLUP" (Throttle system)
Adjust button
- Adjust with the (+) and (-) but-
tons.
- Return to the initial value "0" by
pressing the (+) and (-) buttons
simultaneously for about 1 sec-
ond.
Idle-Up rate (RATE)
D50% ~ D1%, 0%, U1% ~ U50%
Initial value: 0%
"D": Brake side
"U": Forward side
