Chapter 5, “Character LCD Screen,”
describes the functionality of the character LCD
screen.
•
Chapter 6, “VGA Display Port,”
describes the functionality of the VGA port.
•
Chapter 7, “RS-232 Serial Ports,”
describes the functionality of the RS-232 serial ports.
•
Chapter 8, “PS/2 Mouse/Keyboard Port,”
describes the functionality of the PS/2
mouse and keyboard port.
•
Chapter 9, “Digital to Analog Converter (DAC),”
describes the functionality of the
DAC.
•
Chapter 10, “Analog Capture Circuit,”
describes the functionality of the A/D
converter with a programmable gain pre-amplifier.
•
Chapter 11, “Intel StrataFlash Parallel NOR Flash PROM,”
of the StrataFlash PROM.
•
Chapter 12, “SPI Serial Flash,”
describes the functionality of the SPI Serial Flash
memory.
•
describes the functionality of the DDR SDRAM.
•
Chapter 14, “10/100 Ethernet Physical Layer Interface,”
describes the functionality of
the 10/100Base-T Ethernet physical layer interface.
•
Chapter 15, “Expansion Connectors,”
describes the various connectors available on
the Spartan-3E Starter Kit board.
•
Chapter 16, “XC2C64A CoolRunner-II CPLD”
describes how the CPLD is involved in
FPGA configuration when using Master Serial and BPI mode.
•
Chapter 17, “DS2432 1-Wire SHA-1 EEPROM”
provides a brief introduction to the
SHA-1 secure EEPROM for authenticating or copy-protecting FPGA configuration
bitstreams.
•
lists the schematics for the Spartan-3E Starter Kit board.
•
Appendix B, “Example User Constraints File (UCF),”
provides example code from a
UCF.
Additional Resources
To find additional documentation, see the Xilinx website at:
To search the Answer Database of silicon, software, and IP questions and answers, or to
create a technical support WebCase, see the Xilinx website at:
.
