Part
Error message and related information
Relevant LED displays
Meaning of the error and
countermeasures Error message
Information
1
Information
2
Information
3
special
relay RUN FAULT I/O
Program
No SFC macro entry Program
type-
block No.
Macro No. S0006
S0030
o
• O
The macro program specified by macro
step is not programmed. Check that the
macro program has been programmed,
and that the macro No. is correct.
SFC jump label err Program
type-
bloclr No.
SFC label
No. S0006
S0030 o
•
o The SFC label No. is duplicated. Change
the SFC label No.
No SFC jump label Program
type-
block No.
SFC label
No. S0006
S0030
o
•
o The SFC label instruction specified by the
SFC jump instmction is not programmed.
Insert the SFC label instruction.
Duplicate SFC No. Program
type-
block No. SFC
program
No. S0006
S0030 o
•
o The SFC program No. is duplicated.
Change the SFC program No.
Invalid SFC prog Program
type-
block No.
S0006
S0030
o
•
o The correspondences between the initial
step and end step or SFC end, or macro
entry and macro end do not match.
Change the program so that the
correspondence match.
Illegal inst
Program
type-
block No.
Address
in the block S0006
S0030
O •
o An illegal instruction has been detected in
the program.
After executing "Clear memory," reload the
program.
Invalid Fun inst Program
type-
block No.
Address
in the block
FUN No. S0006
S0030
O •
o An instruction which is not su|:^orted by
T3 has been detected. Erase the relevant
instruction.
Boundary error Program
type-
block No.
Address
in the block FUN No. 50064
or
50065
— — —
The operand specified by Indexed FUN
instruction has exceeded the limit. Check
the value of the index register.
Duplicate entry No. Program
type-
block No.
Address
In the block
Entry No. S0006
S0030
O •
o "LBL" or "SUBR" instruction is duplicated.
Check the program.
