1. System Configuration
1.6
Expansion interface
module
If the expansion units are used, the expansion interface modules
must be mounted in each of the basic unit and the expansion units.
There are basically two types of expansion interface modules-the
standard type and the long-distance type. What type to use will
depend on the cable distance. The dedicated expansion interface
module must be mounted on each of the basic unit and the
expansion units.
Type
Use
Remark
IF311
For
basic unit
Standard type
2m maximum between two units,
6m maximum in total cable length
IF351
For
etqjansion unit
IF312
For
basic unit
Long-distance type
40m maximum in total cable length
IF352
For middle
expansion unit
IF353
For end
expansion unit
IF311
(standard type, tor basic unit)
IF351
(standard type, for expansion unit)
iF311
OUT
iS.
Expansion connector (IN)
Connected to tiie preceding unit
Expansion connector (OUT)
Connected to the next unit.
1F351
&
V
IN
OUT
