2. Specification
2.1
General Specifications
Item
Specification
Remarks
>.
o.
CL
3
ai
k.
1
CL
Rated
voltage
(1) 100 to 120 Vac/200 to 240 Vac
Switchable
(2) 24 Vdc
Voltage
tolerance
(1) 85 to 132 Vac/170 to 264 Vac
(2) 20.4 to 28.8 Vdc
Rated
frequency
(1)50/60 Hz
Frequency
tolerance
(1)47 to 63 Hz
Retentive power
Interruption
10 ms or less
Power
consumption
(1) 80 VA or less
Max. load
conditions of one
PS module
(2) 50 W or less
Inrush
current
(1) 10 A/100 Vac, 20 A/200 Vac
(2) 6 A
Insulation
resistance
10 MQ or more (500 Vdc)
Between power
terminals and FG
Withstand
voltage
1500 Vac for 1 minute
Between power
terminals and FG
Operating
temperature
0 to 5Sr
Storage
temperature
-20 to 75*C
Ambient
humidity
20 to 90% RH
No condensation
Atmosphere
No corrosive gases
Dust
10 mg/m3 or less
Vibration
immunity
16.7 Hz, 3 mmp-p, 30 seconds
No power
Shock
immunity
98 m/s2, 3 times, in X, Y, Z
directions
No power
Noise
immunity
1500 Vp-p, 1 M s (noise simulator
method) NEMA ICS3-304
Power supply noise
Grounding
100Q or less
Structure
Control panel built-in t^
Cooling
Natural cooling
Weight
Approx. 7.6 kg
Basic unit with
10 I/O modules
Approx. 4.7 kg
Basic unit with
five I/O modules
26
PROSEC T3
