2. Specification
16-point DC output
Type
Category
Output type
No. of output points
Insulating method
Rated input voltage
Range of load voltage
Max. load current
Voltage drop at ON
Leakage current at OFF
Delay
OFF - ON
ON — OFF
Output signal display
Module status display
External connection
No. of commons
No. of output points
per common
Common polarity
Derating condition
Internal current
consumption
Insulation resistance
W№stand voltage
Built-in fuse
Surge suppressor
Weight
Internal circuit
D0333
Transistor output
Current sinking
16 points, 1-word input (Y 1 W)
Photo-coupler
12 to 24 Vdc
10to30Vdc
2 A/point, 5 A/common
1.5 V or less (at 24 Vdc)
0.1 mA or less (at 24 Vdc)
1 ms or less
1 ms or less
LED display for all points, lit at ON, internal logic side
Fusing/extemal abnormal power supply LED
(FL, FH), lit at abnormal state _______________
20-pin removable terminal block, M3.5
2 (insulated between commons)
8 points per common
negative (-) polarity
See NOTE on the next page
5 Vdc, 320 mA or less
10 MQ (500 Vdc)
1500 Vac, 1 minute (between commons, between
internal and external drcuits)
6 A/commonX2
Diode
41 Og
34
