1. System Configuration
The modules which configure the T3 system are listed below,
(except I/O modules)
Power supply module
Type
Description
1
PS361
Power supply voltage : 100-120 Vac/200-240 Vac,
common for basic and expansion units
2
PS332
Power supply voltage: 24 Vdc,
common for basic and expansion units
CPU module
Type
Description
1
PU315
RAM
2
PU325
RAM+EEPROM
Rack
Type
Description
1
BU31A
For basic
unit
10 slots for I/O modules
2
BU315
5 slots for I/O modules
3
BU35B
For expansbn
unit
11 slots for I/O modules
4
BU356
6 slots for I/O modules
Expansion interface module
Type
Description
1
IF311
For basic
unit
Standard type,
2m maximum between the units,
total 6 m maximum
2
IF351
Fcx expansion
unit
3
IF312
For basic
unit
Long-distance type,
total 40 m maximum
4
IF352
For middle
expan^n unit
5
IF353
For end
expansion unit
Expansion cable
Type
Description
1
CS3R5
0.5m
Standard type,
both-end connector (50-pin)
2
CS301
Im
3
CS302
2m
4
CL3R5
0.5m
5
CL301
1m
6
CU05
5m
Long-distance type,
7
CL310
10m
both^nd connector (68-pin)
8
CL320
20m
9
CL340
40m
10
PROSECT3
