Error message and related information
Relevant LED displays
Meaning of the error and
countermeasures Error message Information
1
Information
2
Information
3
special
relay RUN FAULT I/O
Program
END/IRET error Program
type-
Block No.
Address
in the
block S0006
S0030 O
•
O The "END” instruction has not been found
in the main program or in the subprogram,
or the "IRET” instruction has not been
found in the interrupt program. Write the
"END" instruction or the "IRET" instruction
at the end of the program.
Pair inst error Program
type-
Block No.
Address
in the
block
S0006
S0030
O
•
O An abnormality has been found in
combination of the MCS/R and JCS/R
instructions. Check the combination of
MCS/R and JCS/R instructions is correct.
Operand error Program
type-
Block No.
Address
in the
block S0006
S0030
O
•
O Specifying the operand for the coil
instruction or the FUN instruction is
abnormal. Check that an input (X) is not
allocated to an output operand.
Invalid program Program
type-
Block No.
S0006
S0030
o
•
O An abnormality is detected in the program
management information. Execute "Clear
memory" and re-load the program.
Jump target error Program
type-
Block No.
Address
in the
block
Jump label
No.
soooe
S0030
o
•
o
The "LBL" instruction for the "JUMP"
instruction is not programmed in the same
program type. Or, the "LBL" instruction is
programmed at an address before the
"JUMP" instruction (backward jump).
Insert the "LBL" instruction at the right
position.
