Table 5-4: EXPERT Menu Listing (Continued)
FUNCTION
DESCRIPTION
ENTRY
RANGE
DEFAULT
SOLAR M/F Sub-Menu
MF (1-4)
FUNCTION
Not Applicable
MF (1-4)
SET TEMP
Not Applicable
MF (1-4)
HYST (1-4)
Not Applicable
F15 FUNCTION
F15 Function
00 = Room Sensor for Heating Circuit 2
01 = 0 – 10V iInput
02 = Light sensor
00-02
00
RETURN
Press Program Key to exit SOLAR M/F
Sub-Menu.
5.4.1 Available V-Curve Preset Voltage Curves for 0 – 10 Volt Input
The following listing (Table 5-4) shows the available preset V-Curve settings for operation in
the 0 to 10 Volt Mode:
Table 5-5: V-Curve Preset Voltage Curves for 0 – 10 Volt Input
CURVE NO.
U1
U2
T1
T2
UO
0
2.0 V
10.0 V
32°F
194°F
2.0 V
1
2.5 V
0.3 V
100°F
176°F
5.0 V
2
2.5 V
0.3 V
100°F
167°F
5.0 V
3
2.5 V
0.3 V
100°F
113°F
5.0 V
4
4.0 V
0.1 V
68°F
185°F
5.0 V
5
4.0 V
0.1 V
68°F
167°F
5.0 V
6
4.0 V
0.1 V
68°F
131°F
5.0 V
7
4.0 V
0.1 V
68°F
189°F
5.0 V
8
4.0 V
0.1 V
68°F
189°F
5.0 V
9
4.0 V
0.1 V
68°F
163°F
5.0 V
10
4.0 V
0.1 V
68°F
127°F
5.0 V
11
4.0 V
0.1 V
68°F
194°F
5.0 V
