CHAPTER 5: E8 CONTROLLER MENUS AND SUB-MENUS
Page 32 of 108 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0093_0A
PRI: 06/24/2013 Phone: 800-526-0288 GF-136-C
5.3 TIME PROGRAM Menu and Sun-Menus
Day and Time-related functions can be set using the TIME PROGRAM Menu and its
associated Sub-Menus. However, at the present time, none of the Sub-Menus and functions
in the TIME PROGRAM Menu are being utilized. This menu is shown in Figures 5-5 & 5-6.
Refer to Chapter 9 for additional information on these Menu and Sub-Menu functions.
TIME PROGRAM
CIRCL TIME
MONDAY
TUESDAY
WEDNESDAY
THURSDAY
FRIDAY
SATURDAY
SUNDAY
MO-FR
SA-SU
MO-SU
RETURN
HOTW-PROG
MONDAY
TUESDAY
WEDNESDAY
THURSDAY
FRIDAY
SATURDAY
SUNDAY
MO-FR
SA-SU
MO-SU
RETURN
HTG-PROG 1
MONDAY
TUESDAY
WEDNESDAY
THURSDAY
FRIDAY
SATURDAY
SUNDAY
MO-FR
SA-SU
MO-SU
RETURN
HTG-PROG 2
MONDAY
TUESDAY
WEDNESDAY
THURSDAY
FRIDAY
SATURDAY
SUNDAY
MO-FR
SA-SU
MO-SU
RETURN
Figure 5-5: TIME PROGRAM Menu Flow Chart
TIME TIME
