CHAPTER 3: E8 CONTROLLER OPERATION
Page 14 of 108 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0093_0A
PRI: 06/24/2013 Phone: 800-526-0288 GF-136-C
3.2 Software Menus
Software menus are divided into five main menus, each with a set of sub-menus (Table 3-1).
The rotary knob on the front of the E8 Controller is used to sequentially cycle through the
menus and the sub-menus. Two small arrows at the bottom of the display point to the selected
menu and sub-menu name, respectively. Note that some menus and sub-menus are read-only
or not available, according to the boiler used and the initial startup configuration.
NOTE
Before operating any menus and functions in the E8, one MUST
perform a one-time entry of items into the initial INSTALLATION
menu. See Section 4.1, E8 Controller Initial Startup for more
information about initial setup and configuration of the E8
Controller.
Note that whenever the unit is powered down and then powered
up again, the INSTALLATION menu will reappear. When this
occurs, the INSTALLATION menu items DO NOT need to be
reentered. Normally, after entry of the required initial
INSTALLATION menu entries, turning the Rotary Knob clockwise
will automatically advance the Controller to the DISPLAY menu
group. All items in this group are “Read Only” and cannot be
changed.
Table 3-1: Main Menus and Sub-Menus
MAIN MENUS SUB-MENUS
DISPLAY
INSTALLATION
HOT WATER
HEAT CIRCUIT I
HEAT CIRCUIT II
SOLAR/MF
USER
INSTALLATION
HOT WATER
HEAT CIRCUIT I
HEAT CIRCUIT II
SOLAR/MF
TIME PROGRAMS
CIRCL TIME
HOTW-PROG
HTG-PROG 1
HTG-PROG 2
EXPERT
INSTALLATION
HOT WATER
HEAT CIRCUIT I
HEAT CIRCUIT II
SOLAR/MF
EXPERT HS INSTALLATION
GENERAL
SERVICE
DATE/TIME
HOLIDAY
CLOCK CHANGE
