E8 Controller and BCM for Modulex EXT
Installation, Operation & Maintenance Manual
CHAPTER 5: E8 CONTROLLER MENUS AND SUB-MENUS
OMM-0093_0A AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 Page 27 of 108
GF-136-C Ph.: 800-526-0288 PRI: 06/24/2013
Table 5-1: DISPLAY Menu Listing (Continued)
FUNCTION DESCRIPTION REMARKS
HTG CIRCUIT 1 Sub-Menu
T-ROOM DES A Not Applicable
T-ROOM Current room air temperature.
Only if indoor sensor is
connected
HUMIDITY Room humidity (%).
Only if humidity sensor
is installed and
parameters set for
heating circuit.
T-DHW RATED Hot water set point temperature
Appears only if heating
circuit is programmed
as hot water circuit
T-DHW Current hot water temperature Same as above
T-FLOW RATED Current flow set point temperature
FLOW Current flow temperature
N-OPT-TIME Not Applicable Not applicable
RETURN
Press Program Key to exit HTG
CIRCUIT 1 Sub-Menu.
HTG CIRCUIT 2 Sub-Menu
Functions for HTG (Heating) Circuit 2 are identical to HTG Circuit 1 Functions
above.
SOLAR M/F Sub-Menu
T-MF1
Not Applicable Currently not used
T-MF2 Not Applicable Currently not used
T-MF3 Not Applicable Currently not used
T-MF4 Not Applicable Currently not used
T-COLLECTOR
1
Not Applicable Currently not used
T-DHW Not Applicable Currently not used
T-DHW L Not Applicable Currently not used
RETURN
Press Program Key to exit SOLAR
M/F Sub-Menu.
DISPLAY DISPLAY
