CHAPTER 4: E8 INITIALIZATION AND QUICK START GUIDE
4.1 Initializing the E8 in the Installation Menu
When power is first applied to the boiler and then the E8 controller cover is opened, the
INSTALLATION Menu is displayed once (only). See Figure 4-1 for a diagram of this menu.
These values MUST be entered in order to initialize the boiler for operation. Once the
LANGUAGE, TIME and DATE values grouped here have been entered and accepted, the
controller is initiated and operatable and may be configured for your boiler installation. To re-
enter the INSTALLATION menu, cycle the boiler power and open the cover again.
To initialize the E8 Controller, follow the instructions below and refer to Figure 4-1 and Table 4-1
on the following pages:
Initial Startup INSTALLATION Entry
1. Set the POWER rocker switch, located to the left of the Controller, to the ON (I) position.
2. Open the panel cover on the Controller. The LCD display will read
INSTALLATION. All
values in this level must be entered, in sequence, without interruption.
3. The first function that appears is LANGUAGE. By default, the display should show
ENGLISH. If ENGLISH is not displayed, turn the Rotary Knob until ENGLISH appears.
4. Press the Program Key to store this setting.
5. Next,
TIME will be displayed. Enter the current time (minutes, hours) using the Rotary
Knob. Press the Program Key to store each value.
6. The next items displayed are the YEAR, MONTH and DAY. Enter each item using the
Rotary Knob and press the Program Key as previously described to store the entry.
7. Following entry of all LANGUAGE, TIME and DATE entries, continue entering the
remaining items shown in Figure 4-1 and Table 4-1 until all required items have been
entered. Use the Program Key and Rotary Knob to select, adjust and store all entries as
previously described.
NOTE
Leave the BUS – ID HS parameter blank. Remaining parameters
are already set and do not require any entry.
8. Continue step 7 until RETURN appears in the display, indicating that you are at the end
of the INSTALLATION menu.
9. Press the Program Key to exit the INSTALLATION menu.
