Duet CO
2
Module OEM Implementation Manual
Welch Allyn OEM Technologies Confidential Page 73
EEPROM Maps
System EEPROM Map Table
Word
(hex) Register Description
00 16 bit CRC word/range: 01h to 37h
01 LSB
MSB EEPROM revision #
OEM specific code
02 CO
2
main processor board serial #/range: 0000h to FFFFh
03 LSB Hardware version
04 Barometer gain, unsigned integer/range: 0F00h to 1300h
05 Barometer offset, unsigned integer/range: -8000h to 7FFFh
06 LSB
MSB Pump flow control proportional constant/range: 00h to FFh
Pump flow control integral constant/range: 00h to FFh
07 LSB
MSB Pump flow control derivative constant/range: 00h to FFh
Pump flow control PID SCALE factor constant/range: 00h to FFh
08 LSB
MSB Pump flow control initial flow rate
Pump output limit/range: 0 to 255
09 MSB Pump flow deviation from threshold in cc/min
0A LSB
MSB Occlusion timeout before high pump flow
High pump flow time
0B LSB Pump flow failure timeout
0C LSB
MSB Pressure threshold gain/range: 00h to FFh
Pressure threshold offset, signed integer/range: -80h to 7Fh
0D LSB
MSB Occlusion pump vacuum timeout
Occlusion pump vacuum control & pressure regulated in mmHg
0E IR source gain constant, unsigned integer/range: 0E00h to 11FFh
0H IR source offset constant, signed integer/range: -8000h to 7FFFh
10 LSB
MSB O
2
compensation
N
2
O compensation
11 LSB Desflurane compensation
12 LSB
MSB MS water compensation
SS water compensation
13 LSB
MSB MS BTPS compensation
SS BTPS compensation
14 LSB &
MSB SS baseline compensation
15 LSB
MSB CO
2
waveform data filter/0 = none, 1 = 3 pt (25-50-25), 2 = 3 pt (30-40-30)
ETCO
2
filter
16 LSB
MSB RR filter
InsCO
2
filter
17 LSB
MSB Maximum fast heat PWM
Maximum normal heat PWM
