Duet CO
2
Module OEM Implementation Manual
Welch Allyn OEM Technologies Confidential Page 43
Status Message Code Table
Code (hex) Suggested Message
00 Status OK
01 Invalid Identifier Or Communication Error
02 Invalid Identifier Data
03 Unprotected Operation Violation
06 Acknowledge Mode Command
10 Warm Up In Progress
11 CO
2
Sensor Start Up In Progress
13 Ref Gas Cell Phase Signal Low (advisory)
14 Ref Gas Cell Phase Signal Very Low (error)
15 Barometric Pressure Offset Too Large
16 No Water trap
17 Water trap or Sample Line Occlusion
18 Exhaust Occlusion or Pneumatic Leak
19 Dark Phase Signal Noisy
1A Open Phase Signal Saturated
27 Calculation Error
40 Watchdog Error
44 System EEPROM Error/CRC Code
46 System FLASH ROM Error/CRC Code
47 System Communication Error
4B System RAM Error
4C System RAM Error
4D System FLASH ROM Error/Checksum
4E Stack Overflow Error
4F System SW Error/Main Program
50 CO
2
Sensor Disconnect
51 CO
2
Sensor Manufacturer ID Mismatch
53 No Mainstream Daughter Board
57 No Sidestream Daughter Board
60 CO
2
Sensor EEPROM Error/Revision #
61 CO
2
Sensor EEPROM Error/Checksum
65 CO
2
Sensor EEPROM Error/Read/Write
66 CO
2
Sensor EEPROM Error/CRC Code
70 CO
2
Sensor Temperature Too High
71 CO
2
Sensor Temperature Too Low
72 CO
2
Sensor Warm Up Failure
73 CO
2
Sensor Heater Output Failure
78 CO
2
Sensor Motor Speed Out of Range
79 CO
2
Sensor Motor Start Failure
7B CO
2
Sensor Signal Unable To Sync
7E CO
2
Sensor IR Source Error
80 Pump Failure
81 Unexpected Reverse Flow
82 Unexpected Forward Flow
84 Barometric Pressure Too High
85 Barometric Pressure Too Low
