Duet CO
2
Module OEM Implementation Manual
Page 36 Confidential Welch Allyn OEM Technologies
Mode Command Responses
Host Command Module Response Module Response Format
Enter Autorun Mode
for Mainstream
for Sidestream xx = mode
yy = message
Example:
C = MS and SS hardware present,
mainstream operation
4 = Autorun mode
06 = Acknowledge mode command
Enter Standby Mode
for Mainstream
for Sidestream xx = mode
yy = message
Example:
E = MS and SS hardware present,
sidestream operation
1 = Standby mode
06 = Acknowledge mode command
Enter Warm Standby Mode
for Mainstream (only) Example:
C = MS and SS hardware present,
mainstream operation
2 = Warm Standby mode
06 = Acknowledge mode command
Enter Measurement Mode
for Mainstream
for Sidestream Example:
E = MS and SS hardware present,
sidestream operation
3 = Measurement mode
06 = Acknowledge mode command
Simple Command Response
Host Command Module Response Module Response Format
Request module status xx = mode
yy = message
Example:
6 = MS hardware out, SS hardware
present, sidestream operation
4 = Autorun mode
00 = OK status
