95
Targeting the pedestals
Before shots can be created and stored, all robotic
pedestal movements must reference a target. The target
for each pedestal is either permanently adhered to the
studio floor (Fusion and SP-2000 pedestals) or mounted
at the edge of the studio as a vertical barcode (RP2A
pedestals). Robotic heads mounted on tripods or fixed
mounts, or height drive units do not require targeting.
Studio configurations without pedestals do not need to
reference a target.
Installations with pedestals that are used in multiple
studios will have targets installed in each studio and
named separately – for example, Studio A:Camera 1,
Studio B:Camera 1 and so on.
Fusion pedestal
Pedestal orientation
For simplicity, the sides of the pedestal are referred to as North, South, East or West,
as shown in Fig. 63.
Fig. 63 Fusion FP-145/FP-188 – Pedestal orientation
South side
West side
East side
North side
